PRODUCT OVERVIEW
BenQ Board Master RM8604 86" 4K Interactive Display With Android 13 & EDLA Certified (Master Series):
The BenQ RM8604 86" 4K EDLA Interactive Display is designed to transform modern classrooms into engaging, collaborative, and connected learning environments. Powered by Android 13 with EDLA certification, it brings Google services and Google Play apps directly to the interactive display, while EZWrite 6.0 provides an advanced digital whiteboarding experience for teaching, annotation, presentations, and hybrid learning. With a large 86-inch UHD 4K display, 40-point touch capability, high-precision IR technology, and a zero-gap writing experience, teachers and students can interact naturally with content and work together with ease.
Built for efficient and secure classroom management, the RM8604 combines InstaShare 2 wireless screen sharing, BenQ DMS and AMS management, NFC and QR-code login, cloud file access, AI-powered learning tools, and comprehensive security features. Its ClassroomCare® technologies include Eyesafe® Certified 2.0, TÜV-certified antimicrobial protection, anti-glare treatment, flicker-free operation, and IP5X dust protection, helping create a comfortable learning environment. Front-facing connectivity, a 65W USB-C port, integrated 8-microphone array, and 40W stereo speakers further make the BenQ RM8604 a complete solution for interactive teaching, collaboration, presentations, and video-enabled classrooms.
|
🎓 86" 4K Interactive Display – Enjoy an expansive UHD 3840 × 2160 touchscreen for immersive lessons, presentations, and collaboration. ✍️ 40-Point High-Precision Touch – Let multiple students interact simultaneously with smooth, accurate, paper-like writing. 🤖 AI-Powered Learning Tools – Enhance accessibility with text-to-speech, multilingual translation, and OCR capabilities. ☁️ Google-Powered Classroom – Access Google Play, Google Drive, Meet, Docs, Sheets, and Slides through the EDLA-certified platform. 🖊️ EZWrite 6.0 Whiteboard – Create dynamic lessons with an expandable canvas, templates, math tools, split-screen activities, and file annotation. |
 |
 |
📲 InstaShare 2 Collaboration – Wirelessly share multiple screens, cast content, and control connected devices directly from the board. 🔐 Secure User Access – Use NFC cards or QR-code login to quickly access personalized settings, cloud accounts, and lesson data. 🎙️ AI-Ready Audio & Video – Integrated 8-microphone array and 40W speakers support clear classroom communication and video conferencing. 👁️ ClassroomCare® Protection – Eyesafe® Certified 2.0, anti-glare, flicker-free, antimicrobial, and IP5X dust protection help support healthier classrooms. ⚡ Powerful Connectivity – Multiple HDMI, USB, DisplayPort, VGA, Ethernet, and USB-C ports with 65W power delivery provide flexible device connectivity. |
🎓 86" 4K Interactive Display – Enjoy an expansive UHD 3840 × 2160 touchscreen for immersive lessons, presentations, and collaboration.
✍️ 40-Point High-Precision Touch – Let multiple students interact simultaneously with smooth, accurate, paper-like writing.
🤖 AI-Powered Learning Tools – Enhance accessibility with text-to-speech, multilingual translation, and OCR capabilities.
☁️ Google-Powered Classroom – Access Google Play, Google Drive, Meet, Docs, Sheets, and Slides through the EDLA-certified platform.
🖊️ EZWrite 6.0 Whiteboard – Create dynamic lessons with an expandable canvas, templates, math tools, split-screen activities, and file annotation.
📲 InstaShare 2 Collaboration – Wirelessly share multiple screens, cast content, and control connected devices directly from the board.
🔐 Secure User Access – Use NFC cards or QR-code login to quickly access personalized settings, cloud accounts, and lesson data.
🎙️ AI-Ready Audio & Video – Integrated 8-microphone array and 40W speakers support clear classroom communication and video conferencing.
👁️ ClassroomCare® Protection – Eyesafe® Certified 2.0, anti-glare, flicker-free, antimicrobial, and IP5X dust protection help support healthier classrooms.
⚡ Powerful Connectivity – Multiple HDMI, USB, DisplayPort, VGA, Ethernet, and USB-C ports with 65W power delivery provide flexible device connectivity.
| Brand Name | BenQ | |
| Series Name | Board Master Series | |
| Model Number | RM8604 | |
| Screen Size | 86'' | |
| Panel Type | IPS | |
| Active Area | 1895.0 × 1066.0 mm | |
| Aspect Ratio | 16:9 | |
| Resolution | UHD 3840 × 2160 Pixels | |
| Response Time | 8 ms | |
| Color Depth | 10-bit | |
| Orientation | Landscape | |
| Operation Hours | 18 hours / 7 days | |
| Panel Brightness (Typical) | 450 nits | |
| Contrast Ratio (Typical) | 1200:1 | |
| Dynamic Contrast Ratio | 50,000:1 | |
| Color Gamut | 72% NTSC | |
| Backlight Life (Typical) | 50,000 hrs | |
| Germ-Resistant Technology | Nano-Ionic Silver | |
| Anti-Glare | Yes | |
| Hardness | 9H tempered | |
| Touch Technology | High Precision IR | |
| Touch Points | Up to 40 | |
| Touch Response Time | < 5 ms | |
| HDMI (in | out) | 3 × HDMI 2.0 | 1 × HDMI 2.0 | |
| DisplayPort | 1 × 1.2a | |
| USB-A | 5 × 3.0, 2 × 2.0 | |
| USB-C | 1 × 3.0 (PD 65 W), 2 × 3.0 | |
| USB-B (for touch) | 3 × 3.0 | |
| 3.5 mm Line in (1) | Mic × 1 | |
| VGA | 1 | |
| 3.5 mm Line out | Earphone × 1 | |
| OPS slot (for slot-in PC) | 1 | |
| Wi-Fi | Wi-Fi 6 (optional) | |
| Bluetooth® | Bluetooth 5.2 | |
| S/PDIF out | 1 (optical) | |
| Ethernet | 2 | |
| 3.5 mm Line in (2) | PC Audio × 1 | |
| RS-232 | 1 | |
| NFC Sensor | Yes | |
| Ambient Light Sensor | Yes | |
| IR Sensor | Yes | |
| Microphone | 8-microphone array (range: up to 8 m | 26ft) | |
| Speaker | 2 × 20 W (max) | |
| ENERGY STAR® | Yes | |
| Power Supply | AC 100-240V 50/60Hz | |
| Standby Power Consumption | <0.5 W | |
| Typical Power Consumption | 168.9 W | |
| Operating Temperature | 0°C ~ 40°C | 32°F ~ 104°F | |
| Storage Temperature | -10°C ~ 60°C | 14°F ~ 140°F | |
| Storage Humidity | 10% ~ 80% RH Non-Condensing | |
| Operating Humidity | 20% ~ 80% RH Non-Condensing | |
| Whiteboarding | EZWrite 6.0 | |
| Wireless Screen Sharing | InstaShare 2 | |
| Device Management | DMS | |
| Account Management | AMS | |
| Flicker Free | Yes | |
| Quick Access Tool | Floating Tool | |
| Broadcast System | X-Sign Broadcast | |
| Low Blue Light | Yes | |
| GPU | Arm Mali-G52 MP8 | |
| CPU | Arm Cortex-A73 × 4 + A53 × 4 | |
| Memory | Storage | 8 GB | 32 GB/128 GB | |
| Operating System | Android 13 (EDLA) | |
| Product Dimensions (W x H x D) | 1962.4 × 1174.9 × 87.1 mm | |
| Product Weight | 65.2 kg | |
| Package Dimensions (W x H x D) | 2095.0 × 1265.0 × 185.0 mm | |
| Package Weight | 82.9 kg | |
| Mount (Screws) | VESA 800 × 600 mm ( 4 × M8 × 25L) | |
| Accessories |
1 × VGA (3 m | 9.8 ft), 1 × HDMI (3 m | 9.8 ft), 1 × USB-B for touch (3 m | 9.8 ft), 1 × USB-C (1.5 m | 4.9 ft), 1 × Wall Mount, 2 × Pen, 1 × Remote Control
|
For detailed product specifications, please download the PDF Datasheet.
