High-Performance Christie® Xenolite® Lamps
High-performance Christie® Xenolite® lamps are the best option for illuminating your Christie digital cinema projector and are designed to deliver mission-critical reliability.
More Stable Brightness and Reliability
- More reliable ignition when used in older projectors.
- New performance with the same 99.999% in-theater uptime reliability.
More Usable Hours Per Dollar
- Longer life when used in older projectors.
- Longer warranties mean you can safely use the lamp longer under warranty.
- Fewer lamp replacements mean a lower cost of operation.
- Fewer lamp replacements mean less maintenance.
More Lumens Per Dollar
- Less brightness drop-off means more available brightness.
- Less brightness drop-off means less power required.
- Less power required means lower energy costs and lower cost of operation.
Due to constant research, specifications and features are subject to change without notice.
-
Superior Performance: Enhanced brightness and stability.
-
Longer Lifespan: Up to 1,100 hours with Champion PLUS warranty.
-
Energy-Efficient: Reduces power consumption and operational costs.
-
User-Replaceable: Easy to install and replace.
Estimated Average Expected Life | 1,100 hrs (Champion PLUS warranty) |
Maximum Lumen Output | 15,000 lumens (CP2215) |
Projector Air Extraction Requirement | 450 CFM |
Rated Input Power | 2300W |
Rated Current | 91A |
Rated Voltage | ~25V |
Operating Power Range | 1,610W - 2,300W |
Horizontal | ±5° |
Basal Surface Temperature | 200°C (392°F) max. |
Champion Warranty | 100% warranty to 900 hrs |
Cold Arc Gap | 3.4mm |
Lamp Length (L1) | 225mm |
Lamp Length (L2) | 225mm |
LCL (L3) | 100.5mm |
Bulb Diameter | ø 42mm |
Base Diameter | ø 30mm |
Cathode Pin Diameter | ø M10 x 1.5mm |
Anode Pin Diameter | 14mm2 X 135mm cable / 14-6 terminal |
Forced Air Cooling | 10-13 m/s |
